KD REV II 5-string Fanned Fret bass has proven his ability to provide a monster low B sound. So, here is another one bass I built for a customer looking exactly this sound and of course – an exotic looking instrument.
Technical specification:
Body: Seasoned Bulgarian Alder plus the phenomenal multicolor stabilized Maple burl top. Chambered body.
Neck: CONE CORE neck construction, 2-pieces plain Balkan Maple as sides plus two stripes Purple Heart. European Ash Cone-core.
- Multiscale 34” first string 37” fifth string
- Side position marks 2mm black dots
- 18″ (457,2mm) fingerboard radius
- 20mm (0.787″) thickness at 1-st fret
- 22mm (0.866″) thickness at 12-th fret
- 45mm (1.771″) nut width
- 24 medium Jumbo frets
- Bone nut
Fingerboard: Ebony
Construction: Bolt-on
Tuners: Kluson
Bridge: Monirail, 16,5mm (0.649″) spacing
Pickups: Haeussel BassBar set (neck plus bridge)
Finish: High Gloss Polyester
Strap pins: Standard
Hardware: Chrome
Electronics, controls:
- VOLUME Push/Pull, Active/Passive
- BLEND
- BASS
- MID +-12dB, 500Hz
- HI MIDS +-12dB, 2,8kHz
Darkglass Tone capsule onboard preamp 9V
Weight: 4.450kg (9.8lbs)
Stainless steel electronic box cover plate.
Copper shielding protects the entire electronic box and pickups.
Send me an e-mail via the Contact form to check the availability of the present Fanned Fret bass model or to get more information about placing an order!
Custom options and price are available upon request!
Click on the images to enlarge!
The Fanned Fret bass comes with:
– Gigbag
– Certificate Of Authenticity;
– KD cleaning towel;
